PRODUCT FEATURES
Integrated design for powering lighting device,5V digital product,MP3 display and FM radio.
High efficient PWM charging technology, intelligent management of battery's charging and discharging.
Small volume, low weight and easy to carry.
It can be charged by both by solar energy and city electricity.
SPECIFICATIONS
| Item | JYPS201 | JYPS201A | ||
| Solar Panel | 18V/10W--25W(Mono/Poly) | |||
| Lead-acid Battery | 12V/7AH*1Pcs Deep Cycle Free Maintenance | |||
| Adapter | No | 18V1.5A | ||
| Controller | PWM 12V/3A | |||
| Output Voltage | DC12V3A, USB5V1A | |||
| Charging Mode | PV Charging | PV/City Electricity Charging | ||
| Charging Time | 7.5H by 10W Solar Panel with Sufficient Sunlight, 6.5h by City Electricity |
|||
| 3H by 25W Solar Panel with Sufficient Sunlight, 6.5h by City Electricity |
||||
| Operating Environment | 0-45℃ | |||
| System Case Size | 218*149*164 mm | |||
| Packing Size | 260*190*305 mm | |||
| Net Weight | 3.8 KG | |||
| Standard Cable Spec. | 5m DC Cable+DC Connector | |||
| Battery External Expansion |
Unsupportive | |||
Load Capacity
| Appliance | Spec(W) | Qty(PCS) | Working Hour(h) | Power Consumption(W.h) |
| MP3/FM | 5 | 1 | 2 | 10 |
| Mobile Phone | 5 | 1 | 2 | 10 |
| LED Bulb | 2 | 2 | 5 | 20 |
| Fan | 10 | 1 | 2 | 20 |
| Total： | 60 |
