PRODUCT FEATURES
Mainly power for household appliances and the base station.
Integrated design for charging household appliances.
High efficient PWM charing technology, intelligent management of battery's charging and discharging.
Compact dimension, low weight, easy to carry.
It can be charged both by solar energy and normal city electricity.
SPECIFICATIONS
| Item | JYPS1339 | JYPS1340 | ||
| Solar Panel | 18V/150W(mono/poly) | 18V/300W(mono/poly) | ||
| Lead-acid Battery | 12V/65AH*1Pcs Deep Cycle Free Maintenance |
12V/80AH*1Pcs Deep Cycle Free Maintenance |
||
| Inverter | Pure Sine Wave 300W/12V | |||
| Controller | PWM 12V/15A | |||
| Output Voltage | AC220V | |||
| Charging Mode | PV Charging, City Electricity Adapter Available | |||
| Charging Time | 4Hrs by 150W Solar Panel with Efficient Sunlight |
2.5Hrs by 300W Solar Panel with Efficient Sunlight |
||
| Operating Environment | 0-45℃ | |||
| System Case Size | 510*220*222mm | |||
| Packing Size | 610*1230*300mm | |||
| Net Weight | 26kg | 28KG | ||
| Standard Cable Spec. | 2.5m㎡*5 & Straight MC4 Connector 1 Pair | 2.5m㎡*5 & Straight MC4 Connector 2 Pairs | ||
Load Capacity
| Appliance | Spec(W) | Qty(PCS) | Working Hour(h) | Power Consumption(W.h) |
| Mobile Phone | 5 | 2 | 2 | 20 |
| LED Bulb | 2 | 3 | 5 | 30 |
| Fan | 40 | 1 | 2 | 80 |
| TV | 100 | 1 | 2 | 200 |
| Washing Mc | 240 | 1 | 1 | 240 |
| Total | 570 |
