solar power kit (Economical Series)
-Integrated design, easy install and maintain
-Switch mode: manual & remote control
-Power box: wall mounting & horizontal
-Two working mode: AC & DC
-Safety and stable power supply
-Intelligent battery management, modified sine wave output
- Fault indicator light display ,With perfect protect functions
| Product Name | Specification | JYSY-056A |
| Solar panel | Model No. | JYSY-P50W(poly crystalline) |
| Rated Maximum Power | 50W | |
| Maximum Power | Voltage: 18 Vmp - Current: 2.78Imp | |
| Open Circuit Voltage(Voc) | 21.24V | |
| Short Circuit Current(Isc) | 3.06A | |
| Maximum System Voltage | 1000V | |
| Operating Temperature | -40℃～+85℃ | |
| Standard Test Conditions | 1000W/m2, AM1.5, 25℃ | |
| Lead-acid battery | Nominal Capacity | 12V38AH |
| Solar controller | Rated Voltage(V) | 12V |
| Maximum charging current(A) | 10A | |
| ChargeVoltage(V) | Floating charge: 14.4V,Equalizing charge: 13.8V | |
| Voltage range (V) | 10.8-16.5 V | |
| Operating temp. | -40℃～+60℃ | |
| Inverter | Continuous power(W) | 300W |
| Surge power(W) | 600W | |
| AC output Voltage(V)& Frequency | (V) 220; 50Hz ± 2Hz | |
| Wave form | Modified sine wave | |
| Input: DC 12V | Working Voltage:9.5V-15.5V | |
| Efficiency | ≥70℃ | |
| Thermal protection:≥70℃ | Cooling method:By fan | |
| Storage temperature range | 0℃～40℃ | |
| Alarm:yes | Fuse :45A | |
| DC low voltage shutdown: ≦9.5V | Over voltage shutdown:≤15.5V | |
| PV cables:4mm² *10m; 5m Lamp holder &lamp wire*4PCS; &Other accessories; Manual: 1pc | ||
| Packing Information | ||
| Volume(m³) | 0.063 cbm/set | |
| G.W.(kg) | 24.5 kg/set | |
| Quantity/20GP | 412 set | |
| How much electricity the solar system produce? | ||
| Daily production | 172w-220w | |
| Average monthly production | 5.16kw-6.6kw | |
| Expected annual production | 62.78kw-79.2kw | |
| Max. output power | 300w | |
| Charging mode | solar panel | |
| Charging time | By solar panel about 9 hours. | |
| Working mode | AC & DC | |
| This solar power kit can supply power for mobile phones, lights, fan, tablet PC, laptop, printer, TV, Electrograph etc. Please note that total load power cannot exceed 300w, inductive load power should be less than 200w. | ||
